MSP430 Toolchain on OSX Mavericks

• Install XCode through the OSX App Store
• Open XCode, complete installation
• $ xcode-select --install #installs the xcode command line utilities
• $ sudo xcodebuild -license #necessary for some reason
• Download and install MacPorts
• $ sudo port install msp430-gcc msp430-libc mspdebug

Install the Drivers for the TI Launchpad

• Install GIT
• Clone the updated kext provided by Bert JW Regeer: $ git clone https://github.com/colossaldynamics/ez430rf2500.git
• Instructions for installing the kext are provided in the repository README file.

Compiling and Uploading Test Code to the TI Launchpad

Create the folowing files in a new directory

File main.c (text program code)

#include  <msp430g2553.h>

volatile unsigned int i = 0;

void main(void){
    WDTCTL = WDTPW + WDTHOLD;
    P1DIR |= 0x01;
    for (;;){
        P1OUT ^= 0x01;
        for(i=0; i< 20000; i++){
        }
    }
}

File Makefile (Defines compilation of the code)

DEVICE=msp430g2452
CC=msp430-gcc
CFLAGS=-Os -Wall -g -mmcu=$(DEVICE)
OBJS=main.o
SRCS=main.c

all: main.elf

main.c: watchdog.h

main.elf: $(OBJS)
	$(CC) $(CFLAGS) -o main.elf $(OBJS)

%.o: %.c
	$(CC) $(CFLAGS) -c $<

clean:
	rm -fr main.elf $(OBJS)

flash: main.elf
	mspdebug rf2500 "prog main.elf"

size: main.elf
	msp430-size main.elf

#for managing header file dependencies
depend: .depend

.depend: $(SRCS)
	rm -f ./.depend
	$(CC) $(CFLAGS) -MM $^ -MF  ./.depend;

include .depend

Change the DEVICE variable to match the one on the TI Launchpad

Compile the program:

$ make
$ make flash
$ make verify

You’re done! The program running on the microcontroller should now be blinking the LED on the Launchpad.
